Water cold diesel engine power

3.2KW(18HP）

Diesel engine start type

Manual and electric start

Hydraulic motor power

motor and the flange is whole casting,more durable

Transmission Model

Hydraulic transmission

Mixing system

Hydraulic stirring system with protective device

The number of cylinder

Two

Cylinder structure

Suspended type

easy to Remove the entire cover plate when clean or maintain the cylinders

Cylinder Capacity

400kg*2

500kg*7

600kg*2

Insulation construction

5cm thickness insulation cotton and 1.2mm thickness stainless steel

Bottom of the pot material

High carbon steel alloy

Thickness of tank bottom

10mm

Panel material

Stainless steel

Hydraulic oil tank capacity

70L,please add 70L No.46 anti-wear hydraulic oil

Heating temperature

0-300℃

Recommend discharge temperature

180-220℃

Heating Mode

Diesel &LPG dual-use

N.W

1000kq

1200kg

1250kg

Dimension

1900*1750*1450mm

1900*1750*1550mm

1900*1750*1650mm

Packing Size

2000*1800*1860mm
