Driving type

Electric motor 500W+lithium battery

Paint tank material

Stainess steel

Paint tank capacity

100kg/50L

Glass beads box capacity

20kg

Glass Beads Dispenser

20cm glass beads dispenser

(10/15/20cm adjustable)

Glass Beads Distribution

200-2509/m2

Marking width

Standard Configuration 15cm marking shoe

Optioanl:5/10/12/15/18/20/23/25/30/40/45/50cm

Heat Temperature

180-220℃

Line thickness

1.5-3mm(adjustable)

Max Gradeability

15°

Walking speed

Forward 10km/h,backward 6km/h

N.W

140 kc

G.W

165kg

Dimensions(L*w*H)

900*1260*1000mm

Optional Configuration

Normal road marking shoe,Warn light,Line pattern customized
