Driving type

Manual push

Paint tank material

Stainess steel

Paint tank capacity

100kg/50L

Glass beads box capacity

20kg

Glass Beads Dispenser

20cm glass beads dispenser

(10/15/20cm optional)

Glass Beads Distribution

200-250g/m2

Marking widt

Standard Configuration 15cm marking shoe

Optional:5/10/12/15/18/20/23/25/30/40/45/50cm

Heat Temperature

180-220℃

Line thickness

1.5-3mm(adjustable)

N.W

120 kg

G.W.

145kg

Dimensions(L*W*H)

900*1260*1000mm

Optional Configuration

Normal road marking shoe,Warning light,Line pattern customized
