Water cold diesel engine power

8HP

Diesel engine start type

Manual and electric start

Hydraulic motor power

Motor and the flange is whole casting,more durable

Transmission Model

Hydraulic transmission

Mixing system

Hydraulic stirring system with protective device

The number of cylinder

Single Tank

Cylinder structure

Suspended type,easy to Remove the entire cover plate when clean or maintain the cylinders

Cylinder Capacity

300kg*1

Insulation construction

5cm thickness insulation cotton and 1.2mm thickness stainless steel

Bottom of the pot material

High carbon steel alloy

Thickness of tank bottom

8mm

Panel material

Stainless steel

Hydraulic oil tank capacity

Please add 70L No.46 anti-wear hydraulic oil

Heating temperature

0-300℃

Recommend discharge temperature

180℃ to 220℃

Heating Mode

Liquefied petroleum gas (natural gas),adopt energy-efficient burner

N.W

600kg

G.W.

700kg

Dimension

1790*910*1580 mm

Packing Size

1800*960*1680mm
